SPECIALIST VEHICLE · Electric Industrial Vehicles

Construction Waste Truck

Heavy-Duty Electric Truck for Efficient Construction Debris Transport. Built with robust chassis, dual battery configurations, and high payload capacity, ideal for urban and industrial waste management.

dbff8e410f5ea4823bf245c6a246b03
a429bbe98643f90e308a10cc5bc002a
eed37cb5a6300f3086ee21cdbda3e14
PerformanceDimension · 4060*1450*2050 · Payload · 1500kg
Front/Rear Track Width (mm)1235 · Wheelbase · 2190
Minimum Ground Clearance150mm · Cargo Dimension (mm) · 2600 *1400*1000
Kerb Weight1360kg · Range (Full-Load under flat road condition) · l 50 ~ 60 Km (Standard Battery) l 120 ~ 150 Km ( Advanced Battery)

Original model information

Built around the application.

The original JSH model information is preserved below in a cleaner, easier-to-compare format.

Heavy-Duty Electric Truck for Efficient Construction Debris Transport. Built with robust chassis, dual battery configurations, and high payload capacity, ideal for urban and industrial waste management.

l 50 ~ 60 Km (Standard Battery)

l 120 ~ 150 Km ( Advanced Battery)

Technical data

Product specifications.

Values below reproduce the technical information published for this model. Confirm the final configuration with JSH before ordering.

PerformanceDimension · 4060*1450*2050 · Payload · 1500kg
Front/Rear Track Width (mm)1235 · Wheelbase · 2190
Minimum Ground Clearance150mm · Cargo Dimension (mm) · 2600 *1400*1000
Kerb Weight1360kg · Range (Full-Load under flat road condition) · l 50 ~ 60 Km (Standard Battery) l 120 ~ 150 Km ( Advanced Battery)
Gradeability20% · Maximum Speed · 30 km/h
Electric SystemStandard Controller · Curtis AC Controller · Standard Battery · 72V 200Ah LiFePO4
Advanced ControllerGTAKE AC Controller · Advanced Battery · 96V 200Ah LiFePO4
Standard Motor7.5KW AC Motor · Advanced Motor · 15KW Permanent Magnet Synchronous Motor
Charging Time6~8 hours to fully charged · Charger · Built-in onboard charger
BodyVehicle Body · Cathodic E-coating for Whole Vehicle Body · Dashboard · LCD Dashboard
Lights and signalsHeadlights, Front & Rear Turn signals, Rear Combo Lights, Horn · Auxiliary · Reversing Camera
WindshieldLaminated Glass · Gear Shifter · Shifter style
ChassisPowertrain System · Rear-wheel Drive · Steering System · Recirculating ball steering with EPS
Front Axle & SuspensionIntegral front axle · Rear Axle & Suspension · Integral rear axle with main reducer and differential; plate spring non-independent suspension
Braking SystemHydraulic brakes + vacuum assist, with parking brake device · Tyres · 165/70 R13C Tubeless Tyres
