SPECIALIST VEHICLE · Electric Industrial Vehicles

Flatbed Utility Cart

High-Efficiency Electric Utility Cart with 5000 Kg Towing Capacity. Equipped with a 10KW Permanent Magnet Synchronous Motor (PMS Motor) and 72V 100Ah LiFePO4 battery, designed for heavy-duty logistics and industrial applications.

WechatIMG7079fe0fe9d8112f08c85a2813e53971
WechatIMG3c2836647a48657ad82daba0834dd8ba
WechatIMG0a6f1246156c7a47eac9fb3a1d4796ec
Curb Weight720 kg
Front Axle Weight450 kg
Rear Axle Weight270 kg
Dimensions (L × W × H)3270 × 1120 × 1300 mm

Original model information

Built around the application.

The original JSH model information is preserved below in a cleaner, easier-to-compare format.

High-Efficiency Electric Utility Cart with 5000 Kg Towing Capacity. Equipped with a 10KW Permanent Magnet Synchronous Motor (PMS Motor) and 72V 100Ah LiFePO4 battery, designed for heavy-duty logistics and industrial applications.

Turning Radius 3.5 m

Technical data

Product specifications.

Values below reproduce the technical information published for this model. Confirm the final configuration with JSH before ordering.

Curb Weight720 kg
Front Axle Weight450 kg
Rear Axle Weight270 kg
Dimensions (L × W × H)3270 × 1120 × 1300 mm
Dimensions Including Tow Bar3600 × 1120 × 1300 mm
Wheelbase1560 mm
Front/Rear Wheel Distance980 mm
Payload Capacity1500 kg
Towing Capacity5000 kg
ControllerGTAKE
Motor10 kW Permanent Magnet Synchronous Motor
Battery72V 100Ah LiFePO4 (Lithium Iron Phosphate)
Maximum Speed25 km/h
Instrument PanelDigital Combination Display
Start MethodOne-Touch Start + Pedal Switch
Parking SystemElectronic Parking System
ChargerOnboard Charger (Waterproof, Dustproof, Shockproof)
Tire Size165/70 R13C
Max Load per Tire560 kg
Steering SystemEPS + Triangular Steering Gear + Single Output Rack & Pinion Steering Motor
Suspension SystemHeavy-Duty Type 250 Leaf Spring Front & Rear Axle + Leaf Springs + Hydraulic Shock Absorbers
Braking SystemElectronic Brake Assist
Lighting SystemFront Combination Headlights (High Beam, Turn Signals, Driving Light, Reverse Light, Brake Light)
Cargo Bed Size1950 × 1120 mm

Model inquiry & support

Ask about Flatbed Utility Cart.

Tell us your market, application, quantity, and timing. We will confirm the appropriate configuration or suggest a current alternative.

Contact the JSH teamSee current U.S. stock
