SPECIALIST VEHICLE · Electric Industrial Vehicles

Rear-lift Garbage Truck

High-Performance Electric Garbage Truck with Enhanced Terrain Adaptability. Designed for urban and off-road waste management, featuring dual battery configurations, robust chassis, and advanced safety systems.

WechatIMG3511
WechatIMG3512
WechatIMG3514
PerformanceDimension (L * W * H) (mm) · 4480*1600*1975 · Payload · 1500kg
Front/Rear track width (mm)1240 · Wheelbase (mm) · 2090
Minimum Ground Clearance (mm)150 · Cargo Volume · ~ 3.2m3
Kerb Weight1400kg · Range (Full-Load under flat road condition) · l 50 ~ 60 Km (Standard Battery) l 120 ~ 150 Km (Advanced Battery)

Original model information

Built around the application.

The original JSH model information is preserved below in a cleaner, easier-to-compare format.

High-Performance Electric Garbage Truck with Enhanced Terrain Adaptability. Designed for urban and off-road waste management, featuring dual battery configurations, robust chassis, and advanced safety systems.

l 50 ~ 60 Km (Standard Battery)

l 120 ~ 150 Km (Advanced Battery)

Technical data

Product specifications.

Values below reproduce the technical information published for this model. Confirm the final configuration with JSH before ordering.

PerformanceDimension (L * W * H) (mm) · 4480*1600*1975 · Payload · 1500kg
Front/Rear track width (mm)1240 · Wheelbase (mm) · 2090
Minimum Ground Clearance (mm)150 · Cargo Volume · ~ 3.2m3
Kerb Weight1400kg · Range (Full-Load under flat road condition) · l 50 ~ 60 Km (Standard Battery) l 120 ~ 150 Km (Advanced Battery)
Gradeability≥20% · Maximum Speed · 30km/h
Electric SystemStandard Controller · Curtis AC Controller · Standard Battery · 72V 200Ah LiFePO4
Advanced ControllerGTAKE AC Controller · Advanced Battery · 96V 200Ah LiFePO4
Standard Motor7.5KW AC Motor · Advanced Motor · 15KW Permanent Magnet Synchronous Motor
Charging Time6~8 hours to fully charged · Charger · Built-in onboard charger
BodyVehicle Body · Cathodic E-coating for Whole Vehicle Body · Dashboard · LCD Dashboard
Lights and signalsHeadlights, Front & Rear Turn signals, Rear Combo Lights, Horn · Auxiliary · Reversing Camera
WindshieldLaminated Glass · Gear Shifter · Shifter style
ChassisPowertrain System · Rear-wheel Drive · Steering System · Recirculating ball steering with EPS
Front Axle & SuspensionIntegral front axle · Rear Axle & Suspension · Integral rear axle with main reducer and differential; plate spring non-independent suspension
Braking SystemHydraulic brakes + vacuum assist, with parking brake device · Tyres · 165/70 R13C Tubeless Tyres

Model inquiry & support

Ask about Rear-lift Garbage Truck.

Tell us your market, application, quantity, and timing. We will confirm the appropriate configuration or suggest a current alternative.
